Mobile Conveyors
CT140R
The TCS 36-140 Radial Telescopic Conveyor offers our customers a material handling solution for the quarrying, mining, terminal ports, and rail transportation industries. The flexibility and efficiency of this conveyor means it can be used in many applications for long and short term with strong resale value. Fully assembled, the unit is a towable road transport product and can also be broken down and packed into three 40ft shipping containers for effective global transportation.
Technical Documentation
Measurements
Stockpile Height
14 ft 4 in
47 m 20 cm
Transport Width (Road Towable)
11 ft 4 in
3 m 46 cm
Transport Height (Road Towable)
14 ft 2 in
4 m 33 cm
Max. Discharge Height
47 ft 2 in
14 m 40 cm
Belt Width
36 Inches
900 mm
Transport Length (Pit Portable)
91 ft 2 in
27 m 79 cm
Transport Length (Road Towable)
89 ft 5 in
27 m 60 cm
Transport Height (Pit Portable)
17 ft
5 m 19 cm
Transport Width (Pit Portable)
10 ft 9 in
3 m 28 cm
Conveyor Length
139 ft 3 in
42 m 45 cm
Productivity
Output Potential
441 US tph
400 tph
- 600 tph
- Road towable
- Telescopic mobile link conveyor
- Packs into three 40ft shipping containers
- Ship loading directly into vessels
- Cost-effective and environmentally friendly method of material transfer
- Increased production capacities to existing applications
- Eliminates the high cost of wheel loader usage
- Safer environment with less dust and carbon emissions
- Reduced operator costs
- Reduced energy consumption
